Glass Layout

A docs layout with a floating, translucent sidebar and header

A docs layout built around floating, translucent (glass-like) panels: the sidebar and header sit on top of the content as rounded, blurred surfaces rather than fixed columns.

Install via Fumadocs CLI

For advanced customization that supported options cannot suffice.

npx @fumadocs/cli@latest customize

Usage

Enable the Glass layout with fumadocs-ui/layouts/glass.

layout.tsx
import { GlassLayout } from 'fumadocs-ui/layouts/glass';
import { baseOptions } from '@/lib/layout.shared';
import { source } from '@/lib/source';
import type { ReactNode } from 'react';

export default function Layout({ children }: { children: ReactNode }) {
  return (
    <GlassLayout {...baseOptions()} tree={source.getPageTree()}>
      {children}
    </GlassLayout>
  );
}

Make sure to update your page import too:

page.tsx
import { ... } from 'fumadocs-ui/layouts/docs/page';
import { ... } from 'fumadocs-ui/layouts/glass/page';

Styles

Unlike other layouts, Glass layout styles are not bundled into the CSS preset, so you don't pay for them unless you use the layout. Import them in your Tailwind CSS file:

Tailwind CSS
@import 'tailwindcss';
@import 'fumadocs-ui/css/generated/glass.css';
@import 'fumadocs-ui/css/neutral.css';
@import 'fumadocs-ui/css/preset.css';

Important to know

  • Glass layout is a client component, you cannot pass unserializable props from a server component.
  • It is opinionated: the sidebar and header are more fixed than the default layout, use Fumadocs CLI or the slots option for customization.

Configurations

The options are inherited from Docs Layout, with minor differences:

  • there is no sidebar option, Glass layout is more opinionated than the default one.
  • additional options (see below).

Layout Tabs

Configure Layout Tabs with the tabs prop, see the linked docs for how to add them. Tabs are shown as a dropdown in the sidebar.

layout.tsx
import { GlassLayout } from 'fumadocs-ui/layouts/glass';
import { baseOptions } from '@/lib/layout.shared';
import { source } from '@/lib/source';
import type { ReactNode } from 'react';

export default function Layout({ children }: { children: ReactNode }) {
  return (
    <GlassLayout
      {...baseOptions()}
      tabs={
        {
          // customize tabs
        }
      }
      tree={source.getPageTree()}
    >
      {children}
    </GlassLayout>
  );
}

AI Chat

The floating header can render an Ask AI button. Pass an aiChat object with the open state and a change handler to control your AI search dialog.

layout.tsx
'use client';
import { GlassLayout } from 'fumadocs-ui/layouts/glass';
import { useState } from 'react';

export function Layout({ children }) {
  const [open, setOpen] = useState(false);

  return (
    <GlassLayout
      aiChat={{ open, onOpenChange: setOpen }}
      // ...
    >
      {children}
    </GlassLayout>
  );
}

Slots

Like other layouts, Glass layout exposes a slots option to override the built-in header, sidebar, and sidebarDrawer (mobile) components, in addition to the shared slots (navTitle, themeSwitch, searchTrigger, languageSelect).

layout.tsx
import { GlassLayout } from 'fumadocs-ui/layouts/glass';

<GlassLayout
  slots={{
    header: MyHeader,
  }}
  // ...
/>;
